产品名称:
Lexmark MB2442adwe;Lexmark MB2546ade、Lexmark MB2546adwe;Lexmark MX421ade;Lexmark MX521de、Lexmark MX521ade;Lexmark MX522adhe、Lexmark MX522dhe;Lexmark XM1242;Lexmark XM1246、Lexmark XM1246i 多功能数码复合机
型号:
476、478、496、636、676、678、679、686
以下文字如果与当地法律法规有所冲突,可能并不适用于那些地区:LEXMARK INTERNATIONAL, INC.以其现状提供此手册,并没有任何保证(不论明示的或暗示的),包括,但不限于以其特定目的进行销售及适用的暗示保证。某些司法管辖区并不准许在某些交易中排除明示的或暗示的保证;因此,这份声明可能并不适用于你方。
本手册中提到的有关产品、程序或服务等并不意味着生产厂商打算将这些产品、程序或服务向所有的国家提供,也不意味着只能使用此产品、程序或服务。任何功能一样的产品、程序或服务,只要不侵犯现有的知识产权,都可以用来替换使用。与其他的产品、程序或服务(除厂商明确标明外)共同操作并进行评估与验证是用户的责任。
如需 Lexmark 技术支持,请转到 http://support.lexmark.com。
如需有关管理本产品使用的 Lexmark 隐私策略的信息,请转到 www.lexmark.com/privacy。
如需有关耗材和下载资源的信息,请转到 www.lexmark.com。
Lexmark、Lexmark 徽标和 MarkNet 是 Lexmark International, Inc. 在美国和/或其他国家的商标或注册商标。
Gmail、Android、Google Play 和 Google Chrome 是 Google LLC. 的商标。
Macintosh, Safari, and AirPrint are trademarks of Apple Inc., registered in the U.S. and other countries. App Store and iCloud are service marks of Apple Inc., registered in the U.S. and other countries. Use of the Works with Apple badge means that an accessory has been designed to work specifically with the technology identified in the badge and has been certified by the developer to meet Apple performance standards.
Mopria® 字标是 Mopria Alliance, Inc. 在美国和其他国家的注册和/或未注册商标。未经授权,不得使用。
PCL® 是 Hewlett-Packard(惠普)公司的注册商标。PCL 是 Hewlett-Packard(惠普)公司包含在其打印机产品中的打印机命令(语言)和函数集合的名称。本打印机设计为与 PCL 语言兼容。这就是说,打印机能够识别在不同应用程序中使用的 PCL 命令,并且打印机仿真与命令相应的功能。
PostScript 是 Adobe Systems Incorporated 在美国和/或其他国家的注册商标。
Wi-Fi® 和 Wi-Fi Direct® 是 Wi-Fi Alliance® 的注册商标。
所有其他商标的所有权属于它们各自的所有者。
下列测量按照 ISO 7779 进行,并且报告符合 ISO 9296 标准。
1 米平均声压,dBA | |
---|---|
打印 | 一面;55(MB2442、MX421、XM1242),56(MB2546、MX521、MX522、XM1246) |
扫描 | 51(MX522、XM1246),54(MB2442、MX421、XM1242、MX521、MB2546) |
复印 | 57(MB2442、MX421、XM1242、MX522、XM1246),58(MX521、MB2546) |
就绪 | 14 |
值可能会有所变化。请参阅 www.lexmark.com 上的当前值。
Per Commission Regulation Decision 97/129/EC Legislative Decree 152/2006, the product packaging may contain one or more of the following symbols.
![]() | This symbol indicates that the packaging may contain corrugated fiberboard. |
![]() | This symbol indicates that the packaging may contain non-corrugated fiberboard. |
![]() | This symbol indicates that the packaging may contain paper. |
For more information, go to www.lexmark.com/recycle, and then choose your country or region. Information on available packaging recycling programs is included with the information on product recycling.
此符号指出静电敏感的部件。在没有先触摸远离该符号的区域内的金属表面时,不要接触靠近这些符号的区域。
在执行维护任务(如清除卡纸或更换耗材)时,为防止静电放电造成的损坏,即使符号不存在,也请在进入或接触打印机的内部区域之前触摸打印机的任何外露金属框架。
工作环境温度 | 10 至 32.2°C(50 至 90°F) |
运输温度 | -40 至 43.3°C(-40 至 110°F) |
存储温度和相对湿度 | 0 至 40°C(32 至 104°F) 8 至 80% RH |
本打印机在美国认证合乎 DHHS 21 CFR,Chapter I,Subchapter J 对分类 I (1) 激光产品的标准,而在其他地区则被认证是合乎 IEC 60825-1: 2014 的分类 I 激光产品。
一般认为分类 I 激光产品不具有危险性。本激光系统及打印机的设计,在一般操作、使用者维护或规定内的维修情况下,不会使人体接触分类 I 以上等级的辐射。本打印机有不可维修的打印头配件,包含具有以下规格的激光器:
类别:IIIb (3b) AlGaInP
标称输出功率(毫瓦):15
波长(纳米):650-670
下表记录了该产品的功率消耗特性。
模式 | 描述 | 功耗(瓦特) |
---|---|---|
打印 | 产品正在从电子输入生成硬拷贝输出。 | 一面;570(MB2442、MX421、XM1242),620(MB2546、MX521、MX522、XM1246) |
复印 | 产品正在从硬拷贝的原始文档生成硬拷贝输出。 | 590(MB2442、MX421、XM1242),630(MB2546、MX521、MX522、XM1246) |
扫描 | 产品正在扫描硬拷贝文档。 | 17.5(MB2442、MX421、XM1242),20(MB2546、MX521、MX522、XM1246) |
就绪 | 产品正在等待打印作业。 | 11.5(MB2442、MX421、XM1242),14.5(MB2546、MX521、MX522、XM1246) |
睡眠模式 | 产品处于高级别能源节省模式。 | 1.3(MB2442、MX421、XM1242),1.5(MB2546、MX521),1.41(MX522、XM1246) |
休眠 | 产品处于低级别能源节省模式。 | 0.1 |
关 | 产品已被插入电源插座中,但电源开关被关闭。 | 0.1 |
前面表格中列出的功耗水平表示平均时间测量值。瞬时功率拉升可能远远超过平均水平。
值可能会有所变化。请参阅 www.lexmark.com 上的当前值。
本产品被设计为使用一种称为睡眠模式的节能模式。“睡眠模式”通过在长期不活动时间内减少电力消耗来节约能源。本产品在指定时间段(称为睡眠模式超时)未被使用后自动进入“睡眠模式”。
本产品的出厂默认“睡眠模式超时”(以分钟为单位): | 15 |
通过使用配置菜单,可以在 1 分钟至 120 分钟之间修改“睡眠模式超时”。如果打印速度小于或等于每分钟 30 页,则只能将超时设置为最多 60 分钟。将“睡眠模式超时”设置为较低的值可以减少能源消耗,但是可能会增加产品的响应时间。将“睡眠模式超时”设置为较高的值可以保持较快的响应速度,但是会使用更多的能源。
本产品被设计为使用一种称为休眠模式的超低功耗操作模式。当以“休眠模式”运行时,所有其他系统和设备都被安全地降低功耗。
“休眠”模式能够以下列任何一种方法进入:
使用“休眠超时”
使用“预定省电模式”
此产品在所有国家或地区的出厂默认“休眠超时” | 3 天 |
打印机在打印作业之后并进入“休眠”模式之前等待的时间可以在一小时和一个月之间修改。
待机电量水平在“休眠”或“关闭”模式下发生。
产品应自动掉电至待机功率 ≤ 1 W。产品出厂时应启用自动待机功能(“休眠”或“关闭”)。
无线型号包含以下模块组件之一:
Lexmark 规格类型/型号 LEX-M07-001;FCC ID:IYLLEXM07001;加拿大工业部 IC:2376A-LEXM07001
Lexmark 规格类型/型号 LEX-M08-001;FCC ID:IYLLEXM08001;IC:2376A-LEXM08001
要确定在您的特定产品中安装了哪些模块化组件,请参考实际产品上的标签。
此设备的辐射输出能量远远低于美国通信委员会(FCC)和其他管制机构有关无线频率辐射暴露的限制。此设备的天线和操作人员之间的距离必须保持至少20厘米(8英寸),以满足FCC和其他管制机构有关无线频率辐射暴露的要求。
以下信息适用于所有 MB2546 (7017-676)、MX521(7017-636 和 7017-676)、MX522 (7017-678) 和 XM1246 (7017-679) 打印机型号。
警告
这是符合 EN 55032 A 类限制的辐射要求和 EN 55024 的抗干扰要求的产品。本产品不可在住宅/居住环境中使用。
这是 A 类产品。在居住环境中,此产品可能造成无线电干扰,在这种情况下,用户可能需要采取适当的措施。
部件名称 | 有毒及有害物质或元素 | |||||
铅 (Pb) | 汞 (Hg) | 镉 (Cd) | 六价铬 (Cr VI) | 多溴联苯 (PBB) | 多溴二苯醚 (PBDE) | |
电路板 | X | O | O | O | O | O |
电源 | X | O | O | O | O | O |
电源线 | X | O | O | O | O | O |
连接器 | X | O | O | O | O | O |
机械配件-杆、辊 | X | O | O | O | O | O |
机械配件-电机 | X | O | O | O | O | O |
机械配件-其他 | X | O | O | O | O | O |
扫描仪配件,仅适用于多功能设备 | X | O | O | O | O | O |
LCD/LED 显示屏 | X | O | O | O | O | O |
此表格基于 SJ/T 11364 规则。 O:表示部件的所有同质材料中有毒和有害物质的含量低于 GB/T 26572 中描述的浓度限制要求。 X:表示部件中至少一种同质材料中的有毒和有害物质含量高于 GB/T 26572 中描述的浓度限制要求。 此产品符合中国 RoHS 指令中有关某些有害物质使用的限制。 ![]() 所有包含在内的产品及其组件的环保使用期限 (EFUP) 经由此处所示的符号标记,除非另有标示。某些组件可能有不同的 EFUP,因此标记以反映之。环保使用期限只有当产品在产品手册中定义的条件下操作时是有效的。 ![]() |
This limited warranty applies to the United States and Canada. For customers outside the U.S., refer to the country-specific warranty information that came with your product.
This limited warranty applies to this product only if it was originally purchased for your use, and not for resale, from Lexmark or a Lexmark Remarketer, referred to in this statement as “Remarketer.”
Lexmark warrants that this product:
-Is manufactured from new parts, or new and serviceable used parts, which perform like new parts
-Is, during normal use, free from defects in material and workmanship
If this product does not function as warranted during the warranty period, contact a Remarketer or Lexmark for repair or replacement (at Lexmark's option).
If this product is a feature or option, this statement applies only when that feature or option is used with the product for which it was intended. To obtain warranty service, you may be required to present the feature or option with the product.
If you transfer this product to another user, warranty service under the terms of this statement is available to that user for the remainder of the warranty period. You should transfer proof of original purchase and this statement to that user.
The warranty period starts on the date of original purchase as shown on the purchase receipt and ends 12 months later provided that the warranty period for any supplies and for any maintenance items included with the printer shall end earlier if it, or its original contents, are substantially used up, depleted, or consumed. Fuser Units, Transfer/Transport Units, Paper Feed items, if any, and any other items for which a Maintenance Kit is available are substantially consumed when the printer displays a “Life Warning” or “Scheduled Maintenance” message for such item.
To obtain warranty service you may be required to present proof of original purchase. You may be required to deliver your product to the Remarketer or Lexmark, or ship it prepaid and suitably packaged to a Lexmark designated location. You are responsible for loss of, or damage to, a product in transit to the Remarketer or the Lexmark designated location.
When warranty service involves the exchange of a product or part, the item replaced becomes the property of the Remarketer or Lexmark. The replacement may be a new or repaired item.
The replacement item assumes the remaining warranty period of the original product.
Replacement is not available to you if the product you present for exchange is defaced, altered, in need of a repair not included in warranty service, damaged beyond repair, or if the product is not free of all legal obligations, restrictions, liens, and encumbrances.
As part of your warranty service and/or replacement, Lexmark may update the firmware in your printer to the latest version. Firmware updates may modify printer settings and cause counterfeit and/or unauthorized products, supplies, parts, materials (such as toners and inks), software, or interfaces to stop working. Authorized use of genuine Lexmark products will not be impacted.
Before you present this product for warranty service, remove all print cartridges, programs, data, and removable storage media (unless directed otherwise by Lexmark).
For further explanation of your warranty alternatives and the nearest Lexmark authorized servicer in your area contact Lexmark on the World Wide Web.
Remote technical support is provided for this product throughout its warranty period. For products no longer covered by a Lexmark warranty, technical support may not be available or only be available for a fee.
Lexmark does not warrant uninterrupted or error-free operation of any product or the durability or longevity of prints produced by any product.
Warranty service does not include repair of failures caused by:
-Modification or unauthorized attachments
-Accidents, misuse, abuse or use inconsistent with Lexmark user’s guides, manuals, instructions or guidance
-Unsuitable physical or operating environment
-Maintenance by anyone other than Lexmark or a Lexmark authorized servicer
-Operation of a product beyond the limit of its duty cycle
-Use of printing media outside of Lexmark specifications
-Refurbishment, repair, refilling or remanufacture by a third party of products, supplies or parts
-Products, supplies, parts, materials (such as toners and inks), software, or interfaces not furnished by Lexmark
TO THE EXTENT PERMITTED BY APPLICABLE LAW, NEITHER LEXMARK NOR ITS THIRD PARTY SUPPLIERS OR REMARKETERS MAKE ANY OTHER WARRANTY OR CONDITION OF ANY KIND, WHETHER EXPRESS OR IMPLIED, WITH RESPECT TO THIS PRODUCT, AND SPECIFICALLY DISCLAIM THE IMPLIED WARRANTIES OR CONDITIONS OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, AND SATISFACTORY QUALITY. ANY WARRANTIES THAT MAY NOT BE DISCLAIMED UNDER APPLICABLE LAW ARE LIMITED IN DURATION TO THE WARRANTY PERIOD. NO WARRANTIES, EXPRESS OR IMPLIED, WILL APPLY AFTER THIS PERIOD. ALL INFORMATION, SPECIFICATIONS, PRICES, AND SERVICES ARE SUBJECT TO CHANGE AT ANY TIME WITHOUT NOTICE.
Your sole remedy under this limited warranty is set forth in this document. For any claim concerning performance or nonperformance of Lexmark or a Remarketer for this product under this limited warranty, you may recover actual damages up to the limit set forth in the following paragraph.
Lexmark's liability for actual damages from any cause whatsoever will be limited to the amount you paid for the product that caused the damages. This limitation of liability will not apply to claims by you for bodily injury or damage to real property or tangible personal property for which Lexmark is legally liable. IN NO EVENT WILL LEXMARK BE LIABLE FOR ANY LOST PROFITS, LOST SAVINGS, INCIDENTAL DAMAGE, OR OTHER ECONOMIC OR CONSEQUENTIAL DAMAGES. This is true even if you advise Lexmark or a Remarketer of the possibility of such damages. Lexmark is not liable for any claim by you based on a third party claim.
This limitation of remedies also applies to claims against any Suppliers and Remarketers of Lexmark. Lexmark's and its Suppliers' and Remarketers' limitations of remedies are not cumulative. Such Suppliers and Remarketers are intended beneficiaries of this limitation.
Some states do not allow limitations on how long an implied warranty lasts, or do not allow the exclusion or limitation of incidental or consequential damages, so the limitations or exclusions contained above may not apply to you.
This limited warranty gives you specific legal rights. You may also have other rights that vary from state to state.
